radiant® Residential Receptacles. Same great features of the TradeMaster devices in a designer package ideal for residential applications.
radiant® Series TR Features
- Part of the radiant® collection of devices.
- High-impact resistant thermoplastic construction.
- Ultrasonic welding of face to back body.
- Side wire accepts #12-#14 AWG solid wire. Pushwire accepts #14 AWG solid only.
- "TR" markings on strap per UL Tamper-Resistant requirements.
- Patented "invisi-shutters" internal shutter system lets plugs in, but keeps keys and other objects out with automatic shutters that block access.
- Safer and more effective than traditional plastic outlet caps or protection plates.
"WR" Weather-Resistant versions available
Tamper Resistant
| Catalog Numb. | Amperage | Voltage | Color | Nema Config. |
| 885TRI | 15 | 125 | Ivory | 5-15R |
| 885TRW | 15 | 125 | White | 5-15R |
| 885TR | 15 | 125 | Brown | 5-15R |
| 885TRGRY | 15 | 125 | Gray | 5-15R |
| 885TRBK | 15 | 125 | Black | 5-15R |
| 885TRLA | 15 | 125 | Light Almond | 5-15R |
| 885TRNICC12 | 15 | 125 | Nickel | 5-15R |
| 885TRGCC12 | 15 | 125 | Graphite | 5-15R |
| 885TRDBCC12 | 15 | 125 | Dark Bronze | 5-15R |
Tamper and Weather Resistant
| Catalog Numb. | Amperage | Voltage | Color | Nema Config. |
| 885TRWRI | 15 | 125 | Ivory | 5-15R |
| 885TRWRW | 15 | 125 | White | 5-15R |
| 885TRWR | 15 | 125 | Brown | 5-15R |
| 885TRWRLA | 15 | 125 | Light Almond | 5-15R |
